IsoFlex Gearbox Coupling IFC-4700-95

$556.08
By Coastline Marine

Isoflex Model: IFC-4700-95

Product Type: Spicer/Uni-Joint Coupling

DOWNLOAD DATA SHEET

IFC-4700-95 Specifications

Feature Metric Imperial
Gearbox Flange Bolt Circle Diameter 95.25 [3 3/4"] 3 3/4
Gearbox Flange Bolt Size 7/16" UNF 7/16" UNF
Gearbox Flange Index Ring Type F F
Gearbox Flange Index Ring Diameter 69.85 [2 3/4"] 2 3/4
Isoflex Coupling Outside Diameter 135 5.31
Isoflex Coupling Inside Diameter 50 1.97
Isoflex Coupling Thickness 36 1.42
Heavy Duty 600 440
Medium Duty 900 660
Pleasure Craft 1000 730
Approx Weight incl. Bolt Set 1.2 2.6
