IsoFlex Gearbox Coupling IFC-4900-95
$923.89
Unit price
/
Unavailable
Couldn't load pickup availability
IsoFlex Gearbox Coupling IFC-4900-95
| Feature | Metric | Imperial |
|---|---|---|
| Gearbox Flange Bolt Circle Diameter | 120.65 [4 3/4"] | 4 3/4 |
| Gearbox Flange Bolt Size | 1/2" UNC | 1/2" UNC |
| Gearbox Flange Index Ring Type | F | F |
| Gearbox Flange Index Ring Diameter | 95.25 [3 3/4"] | 3 3/4 |
| Isoflex Coupling Outside Diameter | 175 | 6.89 |
| Isoflex Coupling Inside Diameter | 50 | 1.97 |
| Isoflex Coupling Thickness | 36.6 | 1.44 |
| Heavy Duty | 1200 | 880 |
| Medium Duty | 1800 | 1320 |
| Pleasure Craft | 2000 | 1470 |
| Approx Weight incl. Bolt Set | 2.1 | 4.6 |
Isoflex Spicer/Uni-Joint Couplings
Spicer or Uni-Joint couplings are used on drive shaft flanges configured to standard Spicer, Uni-Joint or cardan shaft drives. Please check torque demands and contact us to discuss your needs.
