IsoFlex Gearbox Coupling IFC-8100-HT

$2,487.49
By Coastline Marine

Isoflex Model: IFC-8100-HT

Product Type: 8 Stud Coupling

DOWNLOAD DATA SHEET

Feature Metric Imperial
Gearbox Flange Bolt Circle Diameter 190.5 [7 1/2"] 7 1/2
Gearbox Flange Bolt Size M16 SHCS M16 SHCS [5/8" approx.]
Gearbox Flange Index Ring Type M M
Gearbox Flange Index Ring Diameter 152.4 [6"] 6
Isoflex Coupling Outside Diameter 275 10.83
Isoflex Coupling Inside Diameter 95 3.74
Isoflex Coupling Thickness 38 1 1/2
Heavy Duty 8500 6260
Medium Duty 12750 9390
Pleasure Craft Use Medium Use Medium
Approx Weight incl. Bolt Set 7.4 16.3
