Isoflex Gearbox Coupling IFC-8400-HT

$2,512.67
By Coastline Marine

Isoflex Gearbox Coupling IIFC-8400-HT

DOWNLOAD DATA SHEET

Feature Metric Imperial
Gearbox Flange Bolt Circle Diameter 200 7 7/8
Gearbox Flange Bolt Size M16 SHCS M16 SHCS [5/8" approx.]
Gearbox Flange Index Ring Type M M
Gearbox Flange Index Ring Diameter 110 4.33
Isoflex Coupling Outside Diameter 275 10.83
Isoflex Coupling Inside Diameter 75 2.95
Isoflex Coupling Thickness 38 1 1/2
Heavy Duty 8500 6260
Medium Duty 12750 9560
Pleasure Craft Use Medium Use Medium
Approx Weight incl. Bolt Set 6.4 14.1



8 Bolt Couplings

Eight bolt couplings are used on eight bolt hole gearbox output flanges. Spigots or pilots can be either male or female. Isoflex couplings are configured to the most common flanges. On Isoflex 8 bolt couplings, special steel spigots, pilots or registers are fitted to maintain absolute dimensions.

Note: certain couplings need a T-bush kit. Isoflex can supply certain adapters.

* Spicer bolt pattern
